Product name one
CPU32-bit high-performance ARM11 secure CPU memory 64MB SDRAM, 128MB Flash, expandable display 2.4-inch color screen, 320 * 240 resolution, optional 2.4-inch color touch screen, support
Product details
| CPU | 32-Bit high-performance ARM11 secure CPU |
| Memory | 64MB SDRAM, 128MB Flash, expandable |
| display | 2.4-Inch color screen, 320 * 240 resolution, optional 2.4-inch color touch screen, support electronic signature; |
| Keyboard | 10 numeric alphabet keys, 8 function keys, 1 power button, dustproof, waterproof and anti-static |
| Magnetic card reader | Can read the 1/2/3 track data of the magnetic stripe card at the same time, support two-way card swiping, in line with ISO7810, 7811 standards |
| IC card reader | 1, through EMV/PBOC3.0 certification, can read and write EMV cards, supports CPU cards and memory cards |
| SAM card reader | Standard 2, expandable to 3, compliant with ISO7816 standard |
| SD card slot | Optional 1, supports standard MicroSD card reading and writing |
| SIM card slot | 1 inline standard SIM card slot |
| contactless card reader | Optional 1 contactless card reader, certified by QPBOC, Paypass, Paywave; supports ISO14443 Type A/B, Mifare1 RF cards |
| printer | High-speed thermal printer, supports graphics and multiple barcode printing; easy-to-load paper, paper roll diameter 40mm |
| Communication? | Support wireless GPRS communication (850/900/1800/1900MHz), support CDMA communication, optional support for USB/U disk upgrade; 3G (WCDMA/EVDO), Wi-Fi and other communication modes |
| scanning module | Extensible 1D/2D module to meet Alipay, WeChat barcode payment, logistics COD and other application scenarios |
| physical interface | 1 RS232 port, 1 miniUSB port |
| power supply | Output:AC 100~240V/0.6A,50/60Hz Output: DC 9V/2.5A |
| Battery | 7.4V/2200mAh lithium-ion battery, supports long standby for more than 72 hours |
| external dimensions | 178mm(L)78mm(W)60mm(H) |
| Weight? | 430g |
| Environmental requirements | Working temperature: 0 ℃~ + 50 ℃ Storage temperature: -20 ℃~ + 60 ℃ Relative humidity: 5%~ 95% (non-condensing) |
