The frequency conversion speed control device (hereinafter referred to as the frequency converter) changes the output frequency and voltage in real time according to the frequency and load conditions, and has the characteristics of high dynamic performance, fast system response, wide speed regulation range, and good acceleration and deceleration performance.
The contact screen is used for human-machine interaction, the human-machine interface is friendly, and the MCGS configuration software is used to communicate with the control machine, which can realize the visual management of the system, allowing users to monitor the operation of the system and the fault alarm more intuitively. It supports network transmission and remote monitoring, and can switch multiple languages.
| project | parameter selection | |
| input | input voltage | 3、3.3、6、6.6、10KV(*) |
| Allowable voltage fluctuation range | Full load operation, voltage fluctuation ± 10% | |
| Frequency range | 50Hz±10% | |
| Input current harmonic | ≤ 3%, in line with IEEE519-1992 and GB/T14549-93 standards | |
| output | Output voltage range | 3、3.3、6、6.6、10KV(*) |
| Maximum output capacity | 30000KVA | |
| Overall efficiency power factor | Forced air cooling ≥ 0.965, water cooling frequency conversion≥0.98 | |
| Output frequency range | 0-50Hz(*) | |
Double waterway parallel design
Reasonable waterway direction
Using high voltage power devices
Online plug and unplug of waterway connector
